535TS Plus Load Pin
Stainless steel load pin for measuring tension/compression forces in load-bearing pins. Capacities from 2t to 100t, IP67 sealed, 1mV/V output, 150% safe overload, CE/RoHS/Ex certified. Ideal for cranes, hoists, and heavy industrial weighing.
- Material: 2Cr13 Stainless Steel
- Rated Capacities: 1t, 2t, 5t, 10t, 20t, 40t, 70t, 100t
- Full Scale Output: Determined by the Amplifier
- Safe Overload: 150% of full scale
- Breaking Overload: 400% of full scale
- IP Rating: Environmentally Sealed / IP67
- CE, RoHS certified
Please contact us for more info about the part-number information.
Features
- Material: 2Cr13 Stainless Steel
- Rated Capacities: 1t, 2t, 5t, 10t, 20t, 40t, 70t, 100t
- Full Scale Output: Determined by the Amplifier
- Safe Overload: 150% of full scale
- Breaking Overload: 400% of full scale
- IP Rating: Environmentally Sealed / IP67
- CE, RoHS certified
Specifications
| Rated Capacities | 1t, 2t, 5t, 10t, 20t, 40t, 70t, 100t |
|---|---|
| Full Scale Output | Determined by the Amplifier |
| Non-linearity | < ± 0.50% |
| Repeatability | < ± 0.30% |
| Hysteresis Error | < ± 0.50% |
| Creep in 30 minutes | < ± 0.20% |
| Compensated Temperature Range | –10°C to 50°C/14°F to 122°F |
| Storage Temperature Range | -50°C to 85°C/-58°F to 185°F |
| Safe Overload | 150% of full scale |
| Breaking Overload | 400% of full scale |
| Seal Type | Environmentally sealed |
| IP Rating | IP67 |
