OCSM1 Light Duty Crane Scale

  • Capacities: 200lb, 400lb, 600lb, 1Klb, 2Klb
  • Accuracy Class: OIML III
  • Safe Overload: 120% of full scale
  • Breaking Overload: 300% of full scale
  • Die-casting aluminum scale enclosure
  • Stainless steel load receptor
  • Stainless steel shackle
  • Rotatable hook
  • Rechargeable 6V/5Ah battery included
  • Power adaptor 9V/1500mA included
  • Selectable units: kg & lb (lb unit annunciator will turn on if lb is selected and will turn off if set to kg)
  • Infrared remote control included
Capacity 200lb, 400lb, 600lb, 1Klb, 2Klb
Accuracy Class OIML III
Enclosure Material Die-casting aluminum
Display Type LED
Display Digits 5 digits
Display Height 30mm/1.18in
Working Temperature -10°C to 40°C/14°F to 104°F
Safe Overload 120% of full scale
Breaking Overload 300% of full scale
Rechargeable Battery (included) 6V/5Ah
Battery Life 80 hours
Power Adaptor (included) 9V/1500mA
Remote Distance 10m/32.8′
Zero Yes
Tare Yes
Hold Yes
Low battery alarm Yes
Battery supervision Yes
Overload alarm Yes
Auto calibration Yes
3-point linearity correction Yes
Unit switch: kg/lb Yes (lb unit annunciator will turn on if lb is selected and will turn off if set to kg)
Gravity acceleration Yes
Resolution switch Yes
Auto-off set Yes
Idle set Yes

pdf- Download data sheet

pdf- Download User’s Guide

pdf- Download Technical Manual

pdf- Download crane scale comparison chart
