AX-CART Mild Steel
The ANYLOAD AX-CART is a rugged mild steel transport solution purpose-built to carry and protect complete portable axle weighing systems in the field. With capacity to hold up to six AXA-8 Axle Weigh Pads and one AN560 Axle Weighing Indicator, the AX-CART-6B consolidates all components into a single, mobile unit—eliminating multiple trips and simplifying logistics for field operations. The powder-coated mild steel construction provides durability and corrosion resistance, while the removable handle and flip-top lid design maximize accessibility and minimize storage footprint for transportation.
Engineered for portability and stability, the AX-CART features two swivel locking casters and two rigid casters to ensure level, secure transport without tip-over risk. Bolt-mounted casters enable quick replacement, and four external anchor points allow the cart to be securely fastened to trucks or trailers for long-distance transit. The removable cart handle reduces storage requirements and simplifies shipping, making it ideal for organizations that need to move complete weighing systems between job sites.
The AX-CART is the standard transport solution for ANYLOAD’s portable axle weighing ecosystem, serving enforcement agencies, logistics companies, fleet management operations, and field survey teams that require reliable, mobile vehicle weighing capability. Net weight of 256 lb (116 kg) ensures easy maneuverability while maintaining structural integrity under full load conditions.
Features
- Holds up to 6 pieces of AXA-8 Axle Weigh Pads and one AN560 Axle Weighing Indicator
- Equipped with 2 swivel locking casters and 2 rigid casters to ensure stable scale transport
- Bolt-mounted casters allow for quick and easy replacement
- Constructed from mild steel with powder-coated surface finish
- Removable cart handle reduces storage and shipping space requirements
- 4 external anchor points secure the cart to trucks for long-distance transit
- Flip-top lid design enables quick and easy access
Specifications
| Material Construction | Mild Steel with Powder-Coated Surface Finish |
|---|---|
| Casters | 2 Swivel Locking + 2 Rigid (Bolt-Mounted for Easy Replacement) |
| Handle | Removable Cart Handle |
| Lid Design | Flip-Top for Quick and Easy Access |
| Anchor Points | 4 External Anchor Points for Truck Transit Security |
| Maximum Load Capacity | 6 x AXA-8 Axle Weigh Pads + 1 x AN560 Axle Weighing Indicator |
| Dimensions | |
| Length (L) | 52.64″ / 1337.0 mm |
| Length (L1) | 41.34″ / 1050.0 mm |
| Length (L2) | 30.71″ / 780.0 mm |
| Height (H) | 36.42″ / 925.0 mm |
| Height (H1) | 8.27″ / 210.0 mm |
| Height (H2) | 19.69″ / 500.0 mm |
| Width (W) | 25.20″ / 640.0 mm |
| Width (W1) | 23.62″ / 600.0 mm |
| Weight & Part Information | |
| Net Weight | 256 lb / 116 kg |
| Part Number | AX-CART-6B |
