101RSLS S-Beam Load Cell
The 101RSLS-S S Beam Load Cell is a rugged, high-accuracy load cell designed for tension and compression weighing applications. Its robust construction and consistent performance make it ideal for industrial scales, material testing, and force measurement systems.
- Material: Stainless Steel
- Rated Capacities: 0.25lb, 0.5lb, 1lb, 2lb, 3lb, 10lb, 25lb, 50lb, 100lb
- Full Scale Output: 1.0mV/V ± 20%(0.25-0.5lb); 2.0mV/V ± 0.20%(1-100lb)
- Safe Overload: 1800% of full scale (0.25-0.5lb); 1000% of full scale (1-25lb); 200% of full scale (50-100lb) for tension only
- IP Rating: IP40
Features
- Material: Stainless Steel
- Rated Capacities: 0.25lb, 0.5lb, 1lb, 2lb, 3lb, 10lb, 25lb, 50lb, 100lb
- Full Scale Output: 1.0mV/V ± 20%(0.25-0.5lb); 2.0mV/V ± 0.20%(1-100lb)
- Safe Overload: 1800% of full scale (0.25-0.5lb); 1000% of full scale (1-25lb); 200% of full scale (50-100lb) for tension only
- IP Rating: IP40
Specifications
| Rated Capacities | 0.25lb, 0.5lb, 1lb, 2lb, 3lb, 10lb, 25lb, 50lb, 100lb |
|---|---|
| Full Scale Output | 1.0mV/V ± 20%(0.25-0.5lb); 2.0mV/V ± 0.20%(1-100lb) |
| Zero Balance | < ± 0.02mV/V |
| Non-linearity | < ± 0.1% |
| Repeatability | < ± 0.05% |
| Hysteresis Error | < ± 0.1% |
| Creep in 30 minutes | < ± 0.1% |
| Input Resistance | 350Ω ±10Ω |
| Output Resistance | 350Ω ± 5Ω |
| Recommended Excitation | 5V (10V Max) |
| Insulation Resistance | >2 [50V DC] GΩ | Nominal Temperature Range | –10°C to 50°C/-14°F to 122°F |
| Safe Overload | 1800% of full scale (0.25-0.5lb); 1000% of full scale (1-25lb); 200% of full scale (50-100lb) for tension only |
| Seal Type | Environmentally Sealed |
| IP Rating | IP40 |
